J14B Series Ultralight Dual Lock Rectangular Connectors - Professional Solutions by MXTD

Looking for reliable electrical connectivity solutions? Our J14B series Ultralight Dual Lock Rectangular Connectors deliver exceptional performance for demanding applications. These low-frequency electrical connectors feature a dual-locking mechanism that perfectly balances quick operation with reliable use. Built on the proven J14A series connector shell foundation, the J14B series offers enhanced contact density and superior rainproof functionality. You'll appreciate the rounded corner anti-misinsertion design that prevents costly connection errors.

Description

The J14B rectangular connector framework speaks to progressed building in electrical network. These connectors include a dual-locking component that guarantees secure associations whereas keeping up ease of utilize. The plan joins improved rainproof capabilities, making them perfect for challenging natural conditions.

Our connectors meet NI product model requirements and support both OEM and ODM customization options. You can rely on these connectors for consistent performance across various electronic applications.

Specifications

Parameter	Standard Conditions	High Temp/Humid/Rain Conditions
Rated Current	2A	2A
Contact Resistance	Before life: ≤10mΩ After life: ≤15mΩ	Before life: ≤10mΩ After life: ≤15mΩ
Insulation Resistance	≥1000MΩ	High temp: ≥80MΩ Humid: ≥10MΩ Rain: ≥5MΩ
Mechanical Life	500 cycles	500 cycles
Withstand Voltage	800V	Low pressure: 250V
Operating Temperature	-55℃ to +125℃	-55℃ to +125℃
Relative Humidity	90% to 95% at 40±2℃	90% to 95% at 40±2℃
Atmospheric Pressure	101.3kPa to 1.33Pa	101.3kPa to 1.33Pa

Applications

These rectangular connectors excel in numerous applications:

Electronic instruments and measurement equipment
Test and measurement systems
Industrial automation equipment
Military and aerospace applications
Communication systems
Data acquisition systems
Avionics equipment

Functionality

Your J14B series Ultralight Dual Lock Rectangular Connectors provide reliable signal transmission in demanding environments. The dual-locking instrument guarantees secure engagement whereas permitting speedy disengagement when needed.

The upgraded rainproof plan secures against dampness entrance. This makes them appropriate for open air applications and sticky situations where conventional connectors might fail.

Key Features

Compact Design: Lightweight construction saves space and reduces system weight
Panel-Mounted Socket: Easy installation and secure mounting
Crimping Termination: Reliable connection method with customizable cable specifications
Anti-Misinsertion Protection: Rounded corner design prevents incorrect connections
Wide Temperature Range: Operates reliably from -55℃ to +125℃
High Vibration Resistance: Withstands sinusoidal vibration up to 2000Hz
Shock Resistant: Handles acceleration up to 980m/s²

Custom Design

We understand that your applications may require specific modifications. Our engineering team offers comprehensive customization services for the product.

Custom options include:

Modified pin configurations
Special cable lengths and specifications
Custom housing materials
Application-specific environmental sealing
Unique mounting configurations

Our 12+ years of industry experience ensures we can deliver solutions that meet your exact requirements.

Customization Process

Why Choose MXTD

Expert Designing Group: Our talented R&D experts bring over 12 a long time of profound industry mastery to each project.

Quality Fabricating: We keep up strict quality control forms and progressed computerization to guarantee reliable item reliability.

Comprehensive Back: From starting plan through after-sales benefit, we give total bolster for your connector needs.

Fast Reaction: Our experienced group reacts rapidly to specialized request and custom requirements.

Proven Track Record: Since 2014, we've conveyed high-quality arrangements over PXIe frameworks, connectors, and estimation hardware.
