J30 Series Pre-Wired Pigtail Micro Twist Pin Connector

When you need reliable electrical connections in demanding applications, the J30 Series Pre-Wired Pigtail Micro Twist Pin Connector stands out as the perfect solution. These high-density connectors highlight a compact 1.27mm pitch plan that maximizes association proficiency whereas minimizing space prerequisites. Compliant with GJB2446 benchmarks, our J30 Arrangement offers uncommon execution with positive contactors utilizing flexible stranded wire pins for prevalent unwavering quality. Whether you're working on aeronautics frameworks, estimation hardware, or mechanical applications, these connectors provide the reliable interconnects you demand.

Product Description

Our J30 Series combines advanced engineering with practical functionality. Each connector features a robust plastic housing equivalent to the American MD series, ensuring compatibility and reliability. The spiral pin design provides excellent contact retention and electrical performance across temperature extremes.

The series includes seven specifications ranging from 9-pin to 51-pin configurations, giving you flexibility for various project requirements. Tail-end modifications for printed boards make integration seamless, while meeting NI product model requirements ensures broad compatibility.

Specifications

Parameter	Value
Operating Temperature	-55°C to +125°C
Relative Humidity	Up to 95% at 40°C
Rated Operating Current	3A
Contact Resistance	≤ 10 mΩ
Insulation Resistance	≥ 5000 MΩ at room temperature
Dielectric Withstand Voltage	800V at room temperature
Vibration Resistance	10 Hz to 2000 Hz, 196 m/s²
Impact Resistance	735 m/s², 11 ms duration
Mechanical Life	500 cycles
Contact Pitch	1.27 mm
Pin Configurations	9-pin to 51-pin

Applications

These versatile connectors excel in numerous industries and applications:

Aerospace and Flying: Basic flight frameworks requiring lightweight, solid connections

Military Gear: Unforgiving environment applications requesting tough performance

Test and Estimation: Exactness disobedient requiring steady electrical interfaces

Industrial Robotization: Control frameworks requiring compact, high-density connections

Medical Gadgets: Hardware where space imperatives and unwavering quality are paramount

Telecommunications: Communication frameworks requiring tried and true flag transmission

Functionality

The J30 Series Pre-Wired Pigtail Micro Twist Pin Connector ( Micro-D series ) provides reliable electrical interconnections between cables, cables and PCBs, and PCBs within your system. The high-density design maximizes your connection capabilities while maintaining a lightweight profile.

These connectors withstand strong vibrations and impacts, making them ideal for applications where space is limited and weight reduction is critical. The elastic stranded wire pins ensure consistent contact pressure and electrical continuity throughout the connector's operational life.

Key Features

GJB2446 Compliance: Meets rigorous military and aerospace standards
High-Density Design: 1.27mm pitch maximizes connections in minimal space
Elastic Stranded Wire Pins: Superior contact reliability and retention
Wide Temperature Range: Operates reliably from -55°C to +125°C
Multiple Configurations: Seven specifications from 9-pin to 51-pin
Vibration Resistant: Withstands frequencies up to 2000 Hz
PCB-Ready Options: Tail-end modifications for easy board mounting
Lightweight Construction: Plastic housing reduces overall system weight

Custom Design

MXTD understands that every project has unique requirements. Our experienced engineering team offers comprehensive OEM/ODM customization services for your specific applications. Whether you need modified pin configurations, special materials, or unique mounting solutions, we work with you to develop the perfect connector solution.

Our customization capabilities include:

Modified pin counts and arrangements
Special housing materials and colors
Custom cable assemblies and harnesses
Unique mounting configurations
Application-specific testing and validation

Customization Process

Why Choose MXTD

With over 12 years of industry expertise, MXTD has built a reputation for delivering exceptional quality and service. Our comprehensive approach ensures you receive not just products, but complete solutions:

Expert Building: Our talented R&D group brings profound specialized information to each extend, guaranteeing ideal execution and reliability.

Quality Confirmation: Progressed robotization and strict quality forms ensure reliable item brilliance and long-term reliability.

Responsive Benefit: We react rapidly to your needs, giving both standardized and customized arrangements to meet tight extend timelines.

Reliable Conveyance: Joining forces with trusted coordinations suppliers, we guarantee secure, opportune conveyance with full following and protections coverage.

Comprehensive Back: From introductory plan discussion through after-sales benefit, our group gives progressing back to guarantee your success.

Certifications and Certificates

Logistics and Transportation

FAQ

Q: What makes the J30 Arrangement diverse from other small scale connectors?

A: The item highlights versatile stranded wire pins that give predominant contact unwavering quality compared to strong pins. The 1.27mm pitch offers higher thickness than numerous alternatives.

Q: Can these connectors handle cruel environments?

A: Yes, they're outlined for extraordinary conditions with working temperatures from -55°C to +125°C and amazing vibration resistance up to 2000 Hz.

Q: Are custom arrangements available?

A: Completely. We offer comprehensive OEM/ODM customization counting adjusted stick tallies, uncommon materials, and interesting mounting solutions.

Q: What's the ordinary lead time for standard configurations?

A: Standard setups regularly dispatch inside 2-3 weeks. Custom plans may require extra time depending on complexity.

Q: Do you give specialized back amid installation?

A: Yes, our specialized group gives comprehensive bolster all through your venture, from beginning choice through establishment and progressing upkeep.
