MDM1 Series Micro Rectangular Electrical Connector

MDM1 Series Micro Rectangular Electrical Connector

When you need reliable electrical connections in compact spaces, the MDM1 Series Micro Rectangular Electrical Connector delivers exceptional performance and versatility. This inventive connector arrangement combines auxiliary compactness with rationalized plan, making it profoundly prescribed for requesting applications. With contact dividing of fair 1mm and push dispersing of 0.866mm, the MDM1 Arrangement offers predominant contact thickness whereas keeping up extraordinary unwavering quality and execution standards.​​​​​​​

Product Portrayals from the Supplier

Our smaller scale rectangular connectors include a basically compact and rationalized plan that maximizes space effectiveness without compromising execution. The item lineup incorporates standardized arrangements with 5, 9, 15, 21, 25, 31, 37, 51, 66, 74, and 100 contacts to meet different application requirements.

Each connector obliges wire creasing with cross-sections extending from 0.035mm² to 0.1mm², guaranteeing compatibility with different wire gages. The items comply with GJB244 common determination benchmarks and meet NI item show prerequisites, ensuring reliable quality and reliability.

Description

These high-performance connectors exceed expectations in applications requiring miniaturized arrangements without relinquishing electrical astuteness. The lightweight development and tall contact thickness make them perfect for space-constrained situations where conventional connectors would be impractical.

Multiple raise end alternatives give plan adaptability, counting wire leads, patch glasses, straight PCB pins, and right-angle PCB pins. This flexibility permits consistent integration into different framework designs and circuit board layouts.

Specifications

Applications

These versatile MDM1 Series Micro Rectangular Electrical Connectors serve multiple industries and applications:

• Test and Measurement Equipment: Perfect for PXI systems and automated test equipment
• Aerospace and Avionics: Reliable connections for flight control systems and communication equipment
• Medical Devices: Compact solutions for portable diagnostic equipment
• Industrial Automation: Control systems requiring high-density connections
• Data Acquisition Systems: High-performance signal transmission
• Simulation Environments: Precise connections for simulation hardware

Functionality

The connector framework gives secure electrical associations through precision-engineered contacts that keep up moo resistance and tall unwavering quality. The fixed plan ensures against natural components whereas guaranteeing reliable execution over extraordinary temperature ranges.​​​​​​​

Advanced contact innovation minimizes flag corruption and keeps up electrical astuteness all through the connector's operational life. The strong mechanical plan withstands rehashed mating cycles whereas keeping up ideal electrical characteristics.

Key Features

• Compact Design: Maximizes contact density in minimal space
• Multiple Contact Options: Available in 5 to 100 contact configurations
• Versatile Terminations: Wire leads, solder cups, straight and right-angle PCB options
• Environmental Protection: Sealed construction for harsh environments
• High Reliability: 500 mating cycle life with consistent performance
• Standard Compliance: Meets GJB244 and NI product requirements
• Precision Engineering: 1mm contact spacing with 0.866mm row spacing

Custom Design

We understand that standard solutions don't always meet specific requirements. Our expert team provides comprehensive OEM/ODM customization services to develop connectors tailored to your exact specifications.

Custom options include modified contact arrangements, specialized termination methods, unique housing materials, and application-specific environmental ratings. Our experienced engineers work closely with you to ensure optimal performance in your specific application.

Why Choose MXTD

With over 12 years of deep industry expertise, Xi'an Mingxi Taida Information Technology Co., Ltd. has established itself as a trusted partner for high-quality connector solutions. Our commitment to excellence drives everything we do.

Expert Engineering Team: Our skilled professionals bring extensive experience in research, development, and production to every project.

Quality Assurance: Strict quality control processes ensure every MDM1 Series Micro Rectangular Electrical Connector meets our rigorous standards.

Comprehensive Bolster: From starting plan meeting through after-sales benefit, we give total bolster all through your venture lifecycle.​​​​​​​

Reliable Conveyance: Joining forces with trusted coordinations suppliers guarantees secure, convenient conveyance with full following and protections coverage.

FAQ

Q: What wire gages are congruous with these connectors?

A: The connectors oblige wire creasing with cross-sections from 0.035mm² to 0.1mm².

Q: Can these connectors work in extraordinary temperatures?

A: Yes, they work dependably from –55°C to +125°C.

Q: How numerous mating cycles can I expect?

A: The mechanical life rating is 500 mating cycles beneath ordinary working conditions.

Q: Are custom setups available?

A: Completely! We offer comprehensive OEM/ODM customization administrations to meet your particular prerequisites.

Q: What standards do these connectors meet?

A: They comply with GJB244 general specification standards and meet NI product model requirements.

Contact Us

Ready to discuss your connector requirements? Our technical experts are here to help you select the perfect solution for your application. Whether you need standard configurations or custom designs, we're committed to delivering excellence.

Get in touch with us today at manager03@mxtdinfo.com to explore how our MDM1 Series Micro Rectangular Electrical Connector can enhance your next project.
