J30JZ Series Stranded Wire Insertion Electrical Connector

Looking for reliable, high-density electrical connectors for your industrial applications? The J30JZ Series Stranded Wire Insertion Electrical Connector delivers exceptional performance in a compact design. These connectors meet exacting GJB2446A guidelines and highlight inventive stranded-wire versatile pins that guarantee solid associations. With their metal casing and decreased impression, they offer prevalent space proficiency compared to ordinary models. Accessible in numerous contact setups, these connectors give flexible arrangements for requesting environments.

Description

Our J30JZ arrangement speaks to a breakthrough in connector innovation. The compact plan decreases generally measurements essentially whereas keeping up strong execution characteristics. These connectors highlight male contacts with stranded-wire flexible pins, moreover known as turned pins, which give fabulous electrical contact and mechanical stability.

The metal casing development guarantees strength and electromagnetic protecting. Each connector experiences thorough testing to meet military-grade measures, making them reasonable for aviation, defense, and mechanical applications where unwavering quality is critical.

Specifications

Parameter	Specification
Operating Temperature	-55°C to +125°C
Rated Current	3A maximum
Contact Resistance	≤ 10 mΩ
Insulation Resistance (Normal)	≥5000 MΩ
Insulation Resistance (Damp Heat)	≥1 MΩ
Withstand Voltage	600V
Vibration	10–2000Hz, 196 m/s²
Shock	735 m/s², 11ms duration
Mechanical Life	2000 cycles
Contact Pitch	1.27mm
Row Spacing	1.1mm
Available Contacts	9, 15, 21, 25, 31, 37, 51, 66, 74, 100

Applications

These connectors excel in demanding environments where space constraints and reliability are paramount. Common applications include:

Aerospace Systems: Avionics, flight control systems, and navigation equipment
Defense Electronics: Military communication systems and radar equipment
Industrial Automation: Control panels, robotics, and measurement systems
Test Equipment: Data acquisition systems and instrumentation
Medical Devices: Diagnostic equipment and monitoring systems

Functionality

The stranded-wire flexible stick plan gives a few utilitarian focal points. These pins keep up steady contact weight all through the connector's operational life. The bent wire development permits for slight misalignment resilience whereas guaranteeing dependable electrical connection.

Each contact point highlights gold plating for upgraded conductivity and erosion resistance. The high-density format maximizes association focuses inside negligible space requirements.

Key Features

Compact Design: 60% smaller volume than conventional J30J models
High-Density Configuration: 1.27mm pitch with 1.1mm row spacing
Military-Grade Performance: Meets GJB2446A standards
Wide Temperature Range: Operates from -55°C to +125°C
Robust Construction: Metal casing with EMI shielding
Multiple Configurations: Ten different contact options available
Long Service Life: Rated for 2000 mating cycles

Custom Design

We understand that standard solutions don't always meet specific requirements. Our engineering team provides comprehensive customization services for the connector series. Whether you need modified contact arrangements, special cable assemblies, or unique mounting configurations, we can develop tailored solutions.

Our OEM/ODM capabilities include custom pin assignments, specialized materials, and application-specific testing protocols for the J30JZ Series Stranded Wire Insertion Electrical Connector. We work closely with you throughout the design process to ensure optimal performance for your application.
