50-Channel PXIe SPST Switches

50-Channel PXIe SPST Switches - High-Performance Testing Solutions

Looking for reliable switching solutions for your test and measurement applications? Our 50-Channel PXIe SPST Switches deliver exceptional performance with 50 single-pole single-throw switch outputs on a standard 3U board. Whether you're working with PXIe, CPCI, PCIe, or PCI transport frameworks, these switches give vigorous flag directing capabilities for requesting test situations. With appraised exchanging capacity of 30VDC@1A and most extreme voltage dealing with up to 220VDC/250VAC, you get the unwavering quality and exactness your applications demand.

Description

Our multi-bus congruous exchanging modules speak to over 12 a long time of building skill in test and estimation arrangements. These modules highlight 50 autonomous SPST channels, each competent of dealing with noteworthy control levels whereas keeping up fabulous electrical execution. The compact 3U shape figure maximizes channel thickness without relinquishing reliability.

Each switch channel employments high-quality transfers with demonstrated electrical life surpassing 100,000 cycles. This guarantees long-term unwavering quality in generation test situations and inquire about applications where reliable execution matters.

Specifications

Physical Dimensions

• PXIe/PXI/CPCI: 160mm × 100mm × 20mm (±0.2mm tolerance)
• PCIe/PCI: 175mm × 106mm × 20mm (±0.2mm tolerance)

Interface Performance

• PXI/CPCI/PCI: 32-bit, 33MHz, 132MB/s
• PXIe/PCIe: x4 lanes, 4Gbps

Applications

These flexible exchanging modules exceed expectations in various test scenarios:

Automated Test Gear (ATE): Course signals between test disobedient and gadgets beneath test with negligible flag degradation.

Production Testing: Handle high-volume testing necessities with solid exchanging execution over thousands of cycles.

R&D Labs: Give adaptable flag directing for model testing and approval work.

Simulation Frameworks: Empower complex test scenarios by directing signals between numerous rebellious and recreation equipment.

Avionics Testing: Bolster aviation and defense applications requiring strong exchanging solutions.

Functionality

The modular design offers exceptional flexibility for your test requirements. Each of the 50 channels operates independently, allowing you to create complex switching matrices or simple signal routing configurations. The 50-Channel PXIe SPST Switches support both manual control through software interfaces and automated control through your test programs.

Software integration happens seamlessly with comprehensive driver support. You get complete control over individual channels or groups of channels through simple programming interfaces. Real-time switching operations integrate smoothly with your existing test sequences.

Key Features

Multi-Bus Compatibility: Support for PXIe, CPCI, PCIe, and PCI buses ensures compatibility with your existing test platforms.

High Channel Density: 50 independent channels in a single 3U slot maximizes your test system's switching capability.

Robust Power Handling: Each channel handles up to 30W switching power with excellent thermal management.

Fast Switching Speed: 3ms close time and 5ms open time enable rapid test execution.

Extended Temperature Range: Industrial-grade options operate reliably from -40℃ to +70℃.

Comprehensive Software Support: Drivers and development tools support Windows, Linux, VXWorks, RTX, and LabVIEW RT.

Long Service Life: Relay contacts rated for over 100,000 switching cycles ensure lasting performance.

Custom Design

Every test application has unique requirements. Our engineering team provides custom modifications to meet your specific needs. Whether you need different connector types, modified switching specifications, or specialized environmental ratings, we can adapt our 50-Channel PXIe SPST Switches to your requirements.

Custom firmware development ensures seamless integration with your test software architecture. We also offer mechanical modifications to fit unique installation requirements or space constraints.

Why Choose MXTD?

Proven Ability: With over 12 a long time in test and estimation arrangements, we get it the challenges you confront in making dependable test systems.

Quality Affirmation: Strict fabricating forms and comprehensive testing guarantee each module meets our tall benchmarks some time recently shipping.

Comprehensive Bolster: Our specialized group gives continuous bolster from beginning meeting through item arrangement and maintenance.

Reliable Conveyance: Joined forces coordinations guarantee secure, followed conveyance with full protections scope. Any shipping issues get prompt consideration and resolution.

Complete Arrangements: Past person modules, we give total estimation and control frameworks custom fitted to your applications.
