32-Channel PXIe DPDT Switches

32-Channel PXIe DPDT Switches - Professional Switching Solutions

When you need reliable switching solutions for your test and measurement applications, our 32-Channel PXIe DPDT Switches deliver exceptional performance and versatility. These professional-grade exchanging modules give 32 channels of dual-pole double-throw exchanging capability, planned to meet the requesting necessities of robotized test hardware, information procurement frameworks, and instrumented applications. With back for different transport interfacing counting PXIe, CPCI, PCIe, and PCI, these switches offer the adaptability you require for advanced test environments.

Description

Our exchanging modules highlight standard 3U board plan with high-density exchanging capability. Each unit gives 32 autonomous DPDT hand-off channels with fabulous electrical execution and long operational life. The modules back different transport interfaces to oblige diverse framework structures and requirements.

These switches are built for applications requiring exact flag steering, automated switching, and dependable execution in requesting situations. The vigorous plan guarantees reliable operation over commercial and mechanical temperature ranges.

Specifications

Applications

These flexible exchanging modules exceed expectations in numerous application areas:

Automated Test Hardware (ATE): Course signals between test disobedient and gadgets beneath test with exact control and timing.

Data Securing Frameworks: Switch between numerous sensors or flag sources for comprehensive estimation campaigns.

Avionics Testing: Bolster complex avionic framework approval with solid exchanging execution in requesting environments.

Laboratory Instrumented: Upgrade estimation adaptability by interfacing numerous rebellious to different test points.

Production Testing: Streamline fabricating test forms with computerized flag directing capabilities.

Functionality

Our exchanging modules give comprehensive usefulness for requesting applications. The dual-pole double-throw arrangement permits you to course signals through two free ways per channel. This plan bolsters differential signals, disconnected exchanging, and complex steering scenarios.

The modules include quick exchanging times with 3ms closing and 5ms opening reaction. This execution empowers fast test arrangements and proficient mechanized operations. Tall electrical appraisals bolster a wide run of flag sorts from low-level estimations to control exchanging applications.

Key Features

High Channel Thickness: 32 channels in standard 3U shape calculate maximizes exchanging capability whereas minimizing rack space requirements.

Multi-Bus Back: Consistent with PXIe, CPCI, PCIe, and PCI interfacing for most extreme framework integration flexibility.

Excellent Electrical Execution: Handle voltages up to 220VDC/250VAC with 1A current capacity for flexible flag handling.

Long Operational Life: Transfer contacts evaluated for over 100,000 exchanging cycles guarantee solid long-term operation.

Wide Temperature Extend: Industrial-grade adaptations work from -40°C to +70°C for unforgiving environment applications.

Comprehensive Computer program Bolster: Total driver bundles and demo programs quicken advancement and deployment.

Custom Design

We understand that standard solutions don't always meet specific requirements. Our experienced engineering team provides comprehensive customization services to adapt these 32-Channel PXIe DPDT Switches to your unique needs.

Customization options include modified electrical ratings, alternative connector configurations, specialized environmental specifications, and enhanced software integration. Our team works closely with you to understand requirements and deliver optimized solutions that meet exact specifications.

Why Choose MXTD?

Deep Industry Encounter: With over 12 years in estimation and control frameworks, we get it the challenges you confront and convey arrangements that work.

Expert Designing Group: Our gifted R&D experts drive persistent advancement while providing specialized bolster all through your venture lifecycle.

Quality Affirmation: Thorough testing and quality control forms guarantee each item meets tall benchmarks for unwavering quality and performance.

Comprehensive Bolster: From beginning discussion through continuous upkeep, our group gives the skill you require for effective extend completion.

Flexible Arrangements: Whether you require standard items or custom plans, we provide arrangements that coordinate your particular prerequisites and budget.

FAQ

Q: Can these switches handle differential signals?

A: Yes, the dual-pole design supports differential signal routing with excellent isolation between channels.

Q: What software development environments are supported?

A: We provide drivers for Windows environments and can customize support for Linux, VxWorks, RTX, and LabVIEW RT as needed.

Q: Are the modules compatible with NI chassis?

A: Yes, our product meet NI product model requirements for seamless integration.

Q: Can switching specifications be modified for specific applications?

A: Absolutely. We offer customization services to modify electrical ratings, timing characteristics, and other specifications.

Q: What is included with module purchase?

A: Each module includes drivers, dynamic libraries, demo programs, and comprehensive documentation for quick integration.

Contact Us

Ready to enhance your test capabilities with our professional 32-Channel PXIe DPDT Switches solutions? Our team is here to help you select the right configuration and provide technical support for your specific application.

Contact our sales team at manager03@mxtdinfo.com to discuss your requirements, request detailed specifications, or arrange product demonstrations. We look forward to helping you achieve your measurement and control objectives with our reliable switching technology.
