PXIe 20-ChannelPower Switches - High-Performance Switching Solutions

Looking for reliable power switching solutions for your test and measurement applications? Our PXIe 20-ChannelPower Switches deliver exceptional performance with 20 single-pole single-throw channels, 10A maximum current, and ultra-low resistance.These progressed exchanging modules are outlined to meet the requesting necessities of cutting edge testing situations whereas giving greatest adaptability and accuracy control.

Product Portrayal from the Supplier

Our control exchanging modules speak to over 12 a long time of designing brilliance. Each unit highlights standard PXIe/CPCI/PCIe/PCI transport compatibility with 3U board plan. The 20-channel arrangement gives comprehensive exchanging capabilities for complex test setups. With on-resistance of fair 30mΩ and most extreme exchanging times beneath 10ms, you get quick, precise exchanging with negligible flag degradation.

Description

These power switching modules excel in demanding test environments. You can control up to 20 independent channels simultaneously. Each channel handles substantial power loads safely. The robust relay design ensures long-term reliability. Your test systems benefit from precise switching control and excellent signal integrity.

The modules integrate seamlessly with existing PXIe systems. Standard form factors ensure easy installation. Professional-grade construction withstands harsh operating conditions. Multiple bus options provide maximum compatibility with your current infrastructure.

Specifications

Parameter	Specification
Channels	20 single-pole single-throw
On-resistance	≤30mΩ
Maximum switching time	≤10ms
Maximum switching current	10A
Maximum switching voltage	125VDC/380VAC
Maximum switching power	300W, 2500VA
Relay electrical life	≥100,000 cycles
Physical dimensions (PXIe)	160mm x 100mm x 20mm
Physical dimensions (PCIe)	175mm x 106mm x 20mm
Operating temperature	Commercial: -20℃ to +60℃ / Industrial: -40℃ to +70℃
Storage temperature	-55℃ to +85℃
Relative humidity	5% to 90% (non-condensing)
Interface options	PXI/CPCI/PCI (32-bit, 33MHz), PXIe/PCIe (x4, 4Gbps)

Applications

Your test and measurement systems gain powerful switching capabilities. These modules excel in automated test equipment configurations. Power distribution testing becomes more efficient and accurate. Signal routing applications benefit from low resistance paths.

Manufacturing test stations utilize these switches for production testing. Research laboratories rely on them for prototype validation. Quality control departments implement them for product verification. Educational institutions use them for training and research projects.

Functionality

Each switching channel operates independently. You control individual relays through software commands. The system responds quickly to switching requests. Status feedback confirms switch positions accurately.

Built-in protection circuits safeguard against overcurrent conditions. Isolation between channels prevents crosstalk. The robust design handles inductive loads effectively. Thermal management ensures stable operation under load.

Key Features

High Current Capacity: Handle up to 10A per channel safely

Low Resistance: Minimize voltage drops with 30mΩ resistance

Fast Switching: Complete operations within 10ms

Long Life: Over 100,000 switching cycles guaranteed

Multiple Formats: Choose from PXIe, CPCI, PCIe, or PCI versions

Wide Voltage Range: Support both DC and AC applications

Professional Software: Compatible with Windows and custom OS options

Custom Design

Every project has unique requirements. Our engineering team adapts these PXIe 20-ChannelPower Switches to meet your specific needs. Custom channel configurations are available. Modified voltage and current ratings can be implemented.

Special connectors and interfacing can be coordinates. Natural determinations can be upgraded for extraordinary conditions. Program customization guarantees consistent integration with your existing frameworks. OEM and ODM associations are invited.

Customization Process
