PXI High Speed 64 Channel Digital IO Module

PXI High Speed 64 Channel Digital IO Module - Professional Testing Solution

Looking for reliable high-speed digital I/O capabilities for your testing applications? The PXI High Speed 64 Channel Digital IO Module delivers exceptional performance with 64 independent channels and advanced timing features. This flexible module gives adaptable input/output arrangements with inspecting rates up to 20MHz. Whether you require exact advanced flag procurement or era, our arrangement guarantees exact comes about for requesting test situations. The strong plan underpins different voltage levels and incorporates comprehensive buffering capabilities for consistent operation.

Product Description

Our high-performance computerized I/O module changes your testing capabilities with professional-grade usefulness. Built on the dependable PXI stage, this module coordinating consistently into existing test frameworks. You get free channel control with adaptable flag course arrangement. The progressed engineering bolsters both high-speed information procurement and flag era simultaneously.

Technical Specifications

Key Applications

Automated Test Equipment (ATE)

Perfect for generation line testing where you require solid advanced flag recreation and capture.

Hardware-in-the-Loop Testing

Ideal for automotive and aerospace applications requiring precise timing control.

Research & Development

Essential for model approval and flag keenness examination in research facility environments.

Manufacturing Quality Control

Excellent for functional testing of digital circuits and communication interfaces.

Advanced Functionality

Independent Channel Control

Configure each of the 64 channels freely for input or yield operations. This adaptability permits you to adjust rapidly to changing test requirements.

Multi-Level Output Support

Generate signals at 1.8V, 2.5V, 3.3V, or 5V levels to coordinate your gadget beneath test details perfectly.

High-Speed Performance

Achieve sampling rates up to 20MHz for demanding real-time applications where timing accuracy matters.

Programmable Timer/Counters

Utilize four 32-bit timer/counters for edge counting, period measurement, and pulse generation tasks.

Outstanding Features

✓ Expansive Buffer Memory - 8M test buffer guarantees nonstop operation without information loss

✓ Adaptable Activating - Numerous trigger sources counting PFI and PXI trigger lines

✓ Strong Assurance - ESD security up to 4kV shields your investment

✓ Wide Temperature Extend - Dependable operation from -10℃ to +55℃

✓ Standard Compliance - Meets NI item demonstrate necessities for compatibility

Custom Design Services

Need specific modifications for your application? Our experienced engineering team provides comprehensive customization services. We adapt the PXI High Speed 64 Channel Digital IO Module to meet your unique requirements. From modified connector configurations to specialized firmware, we deliver solutions that fit perfectly into your test architecture.

Our OEM/ODM capabilities include:

• Custom channel configurations
• Modified output voltage levels
• Specialized timing requirements
• Application-specific firmware development

Why Choose MXTD?

12+ Years Industry Experience

Since 2014, we've been creating cutting-edge PXI arrangements with profound specialized skill. Our group gets it the challenges you confront in advanced test environments.

Expert Engineering Support

Our talented R&D group gives fast reaction to specialized questions and customization demands. You get proficient direction all through your extend lifecycle.

Quality Assurance

Rigorous testing and quality control forms guarantee each module meets strict execution benchmarks. Your applications request unwavering quality - we convey it.

Comprehensive After-Sales Service

We stand behind our items with committed back, speedy investigating, and normal follow-ups to guarantee your proceeded success.

Frequently Asked Questions

Q: Can I mix input and output channels on the same module?

A: Yes, each channel direction is independently configurable, giving you complete flexibility.

Q: What software compatibility does this module offer?

A: The module meets NI product model requirements and integrates with standard PXI software frameworks.

Q: How do I handle different voltage level requirements?

A: The module supports 1.8V, 2.5V, 3.3V, and 5V output levels, covering most common interface standards.

Q: Is the module suitable for harsh industrial environments?

A: Yes, with operating temperatures from -10℃ to +55℃ and robust ESD protection, it handles demanding conditions.
