15.6-inch Dual-Slot Rugged Portable Computer

I. Computer Platform
1. Processor: Intel Core™ i7-7500U processor, base frequency 2.7GHz, turbo frequency 3.5GHz, 2 cores 4 threads, TDP 15W
2. Memory: Standard 8GB DDR4 memory, optional 16GB or 32GB
3. Disk: 1TB wide-temperature SSD
II. LCD Screen
1. Display: 15.6" FHD TFTLCD (high brightness, heated film)
2. Maximum Resolution: 1920x1080
III. I/O Interfaces
1. Ethernet Port: 1 x 100/1000Mbps RJ45 port
2. USB: 2 x USB 2.0, 2 x USB 3.0
3. HDMI: 1 x
4. Expansion Interface: 2 x 3U CPCI slots
IV. Power Supply
1. Power Input: DC28V input
Meets NI product model requirements
OEM/ODM customization supported
Product Description

15.6-inch Dual-Slot Rugged Portable Computer - Professional Testing Solution

Looking for a reliable testing platform that can withstand harsh environments? Our 15.6-inch Dual-Slot Rugged Portable Computer delivers exceptional performance in demanding conditions. This convenient testing arrangement combines effective Intel Core™ i7 handling with tough development. You get military-grade strength and professional-grade usefulness in one compact bundle. Idealize for field testing, research facility work, and mechanical applications where standard computers basically can't perform.

Description

This high-performance versatile computer is designed for experts who require dependable computing control anyplace. The magnesium-aluminum combination development guarantees greatest strength whereas keeping weight reasonable. You'll appreciate the brilliant 15.6-inch high-brightness show that remains unmistakable indeed in shinning open air conditions.

The framework highlights double 3U CPCI development openings, making it culminate for estimation and control applications. Whether you're conducting field tests or running complex recreations, this machine adjusts to your needs. The wide-temperature SSD guarantees your information remains secure, indeed in extraordinary conditions.

Specifications

Component Specification
Processor Intel Core™ i7-7500U, 2.7GHz base, 3.5GHz turbo, 2 cores/4 threads
Memory 8GB DDR4 standard (16GB/32GB optional)
Storage 1TB wide-temperature SSD
Display 15.6" FHD LCD, 1920x1080, 600cd/m² brightness
Operating Temp 0°C to 50°C
Storage Temp -25°C to 60°C
Humidity 10%~95% @40°C (non-condensing)
Vibration 50~500Hz, 1.5g, 0.15mm peak
Shock 10G (11ms)
Dimensions 412mm x 278mm x 74.8mm
Weight 6.2kg (with battery)
Power Input DC28V
Battery Life 2 hours normal operation

Applications

This flexible testing stage serves numerous businesses and applications:

Field Testing & Estimation: Idealize for open air information collection where rough unwavering quality things most.

Industrial Mechanization: Control and screen fabricating forms with certainty in unforgiving plant environments.

Military & Defense: Meets requesting military determinations for vibration, stun, and temperature extremes.

Research & Advancement: Perfect for research facility testing where accuracy and unwavering quality are essential.

Telecommunications: Field upkeep and testing of communication frameworks in different climate conditions.

Functionality

The dual-slot plan gives remarkable expandability for your testing needs. Each 3U CPCI opening acknowledges industry-standard estimation cards. You can design the framework for particular applications without compromising portability.

Multiple network alternatives keep you associated all over. Four USB ports handle your peripherals whereas Gigabit Ethernet guarantees quick information exchange. The HDMI yield lets you interface outside shows for introductions or point-by-point analysis.

Key Features

Rugged Development: Magnesium-aluminum amalgam body withstands drops, vibration, and temperature extremes.

High-Brightness Show: 600cd/m² brightness with warmed film innovation for open air visibility.

Dual Extension Spaces: Two 3U CPCI spaces for estimation and control card integration.

Long Battery Life: 2-hour operation time for amplified field work sessions.

Wide Temperature Run: Works dependably from 0°C to 50°C without execution degradation.

Professional I/O: Gigabit Ethernet, different USB ports, and HDMI for comprehensive connectivity.

Custom Design

Every project has unique requirements. Our engineering team works closely with you to modify this 15.6-inch Dual-Slot Rugged Portable Computer for your specific needs. We can adjust I/O configurations, modify enclosure specifications, or integrate specialized components.

Our OEM/ODM administrations guarantee you get precisely what your application requests. From model to generation, we back your venture each step of the way.

Customization Process

Why Choose MXTD?

12+ A long time of Involvement: Since 2014, we've been conveying solid estimation and control arrangements to requesting industries.

Expert Building Group: Our gifted R&D experts get it the challenges you confront in cruel environments.

Quality Confirmation: Thorough testing and quality control guarantee each unit meets our strict standards.

Comprehensive Bolster: From starting meeting to after-sales benefit, we're here to offer assistance you succeed.

Fast Reaction: Our group reacts rapidly to your specialized questions and customization requests.

Reliable Coordinations: Secure, followed shipping with full protections assurance for your investment.

Certifications and Certificates

Logistics and Transportation

FAQ

Q: Can this computer handle extreme temperatures?

A: Yes, it operates reliably from 0°C to 50°C and can be stored from -25°C to 60°C.

Q: What expansion cards are compatible?

A: The system accepts standard 3U CPCI cards for measurement, control, and communication applications.

Q: How long does the battery last?

A: You can expect approximately 2 hours of normal operation on a full charge.

Q: Is customization available?

A: Absolutely! We offer OEM/ODM services to modify the system for your specific requirements.

Q: What operating systems are supported?

A: The system supports Windows 7, Windows 10, and other compatible operating systems.
