J14A Series Low RF Rectangular Screw Lock Connectors

Looking for reliable electrical connectors for your electronic systems? The J14A Series Low RF Rectangular Screw Lock Connectors offer exceptional performance and versatility for various applications. These low-frequency electrical connectors feature a double-safety locking mechanism that perfectly balances quick operation with reliable use. With their compact, lightweight design and rounded corners to prevent reverse insertion, the products deliver the dependability you need for critical connections. Xi'an Mingxi Taida brings you proven connector solutions backed by over 12 years of industry expertise.

Description

Our rectangular electrical connectors are designed to meet requesting execution benchmarks whereas keeping up ease of utilize. The inventive plan joins adjusted corners that dispense with the plausibility of off base inclusion, guaranteeing your associations are continuously secure and legitimately aligned.

The double locking framework gives certainty in high-vibration situations. You get the comfort of speedy associations without relinquishing unwavering quality. This makes these connectors perfect for applications where visit gathering and dismantling are required.

Each connector experiences thorough quality testing to guarantee steady execution. The compact frame calculate spares important space in your plans whereas conveying strong electrical characteristics.

Specifications

Parameter	Value
Rated Current	3A
Contact Resistance (Before Life Test)	≤6mΩ
Contact Resistance (After Life Test)	≤10mΩ
Insulation Resistance (Standard Conditions)	≥2000MΩ
Insulation Resistance (High Temperature)	≥1000MΩ
Insulation Resistance (Humid Conditions)	≥20MΩ
Mechanical Life	500 cycles
Withstand Voltage (Standard Conditions)	800V
Withstand Voltage (Low Pressure Conditions)	250V
Solder Wire Hole Diameter	Ø0.6mm
Recommended Wire Cross-Section	0.15mm² (max 0.2mm²)
Solder Pin Diameter	Ø0.6-0.7mm

Applications

These versatile connectors excel in numerous electronic applications. You'll find them particularly useful in:

Electronic test instruments and measurement equipment
Data acquisition systems
Industrial automation equipment
Communication devices
Laboratory instrumentation
Avionics systems
Control panels and interfaces

The connectors maintain excellent signal integrity across various operating conditions. They're designed to handle the electrical demands of modern electronic systems while providing long-term reliability.

Functionality

The connector system offers multiple termination options to suit your specific needs. When using solder cup terminations, the precise hole diameter ensures consistent solder joints. The recommended wire gauge specifications help you achieve optimal electrical performance.

For PCB applications, both straight and 90-degree bent insertion options are available. This flexibility allows you to optimize your board layout and manage space constraints effectively.

The mechanical design ensures positive engagement with each connection. You'll know when the J14A Series Low RF Rectangular Screw Lock Connectors are properly seated, reducing the risk of intermittent connections or system failures.

Key Features

Double-Safety Locking Mechanism: Provides secure connections while allowing quick assembly and disassembly operations.

Reverse Insertion Prevention: Rounded corner design eliminates connection errors and potential damage to your equipment.

Compact Form Factor: Lightweight construction saves space and reduces overall system weight.

Multiple Configuration Options: Available in pin-type and socket configurations for maximum design flexibility.

Superior Electrical Execution: Moo contact resistance and tall separator resistance guarantee dependable flag transmission.

Robust Development: Built to withstand 500 mechanical cycles whereas keeping up electrical specifications.

Standards Compliance: Meets GJB142A-94 national military standard prerequisites for requesting applications.

Custom Design

Every extend has special necessities. Our designing group works with you to create custom arrangements that meet your particular needs. Whether you require altered stick arrangements, extraordinary materials, or interesting shape variables, we can help.

Our plan prepare starts with understanding your application necessities. We at that point create models for testing and approval. This collaborative approach guarantees the last item meets all your execution and unwavering quality expectations.

Custom arrangements can incorporate specialized plating alternatives, improved natural fixing, or adjusted electrical appraisals. Our experienced group guides you through the whole advancement process.
