The system simulator inspection station is a portable detection device specially developed for underwater instruments. This device is a component of the joint debugging test system. It is used during the system joint test process to conduct real-time detection, recording of each communication link, to determine whether the system is operating normally, and to monitor the entire joint test process, guiding the joint test to be carried out according to the prescribed procedures.

Technical Specifications

The main functions of the system simulator inspection station：

The simulation alarm system responds to the firing parameters and promptly executes the commands of the relevant units, completing the reporting of the alarm data.

Simulate the relevant detection procedures before the shooting, mainly including the connectivity check of the system, external power supply, self-check, inertial navigation alignment, pre-setting, internal power supply, and launch abort, etc. all of which provide feedback information.

Major component

The system simulator inspection station is composed of two portable waterproof boxes. One is the main control box, and the other is the load box.

1)The main control box is composed of the main controller, human-machine interaction unit, multi-function board, external power supply detection unit, system power supply, test interface, and test cable, etc.

All the above units are installed as a whole in the inner box, which is placed inside the waterproof outer box.
The main control unit is the core for controlling and processing data of this inspection platform.
The human-computer interaction unit includes an 8-inch high-brightness touch screen, keyboard, and various operation buttons on the operation panel.
The multi-function board is used to collect information such as external power supply voltage, current, and fire control instructions.

2)Load box, mainly used for installing load power resistors, and the top of the box can also store components such as test cables and power cables.

Key Features

The functions of the online working state of the main control units of the various elements are tested, including the various element calculation units and the control devices.

Conduct a separate functional check on the actuating device only.

This device is equipped with self-checking function and abnormal alarm function. Once an alarm is triggered, it can be set to automatically resume the normal detection process or to perform fault inspection items. It can also detect the power supply capacity and power supply timing sequence of the control device, as well as the corresponding process.
