12-Channel Serial Communication Card

12-Channel Serial Communication Card - Professional RS422 Multi-Port Solution

Looking for a reliable multi-channel communication solution for your industrial systems? Our 12-Channel Serial Communication Card delivers exceptional performance with advanced RS422 interface technology. This professional-grade card underpins different transport measures counting PXIe, CPCI, PCIe, and PCI arrangements. Whether you require high-speed information transmission or strong mechanical communication, this item gives the adaptability and unwavering quality your applications demand.

Product Description

Our multi-port serial communication card speaks to cutting-edge innovation in mechanical information transmission. Built on standard 3U board design, this arrangement suits twelve synchronous RS422 channels for bidirectional communication. The card bolsters flexible baud rates extending from 2400bps to 4Mbps, making it appropriate for differing mechanical environments.​​​​​​​

Each channel offers configurable information parameters counting 5-8 bit information length, variable halt bit settings, and numerous equality modes. The strong plan guarantees dependable operation in challenging mechanical conditions whereas keeping up compatibility with industry-standard transport interfaces.

Technical Specifications

Applications

Industrial Automation Systems

Perfect for manufacturing plant mechanization systems requiring numerous gadget associations and real-time information exchange.

Testing and Measurement Equipment

Ideal for robotized test hardware (ATE) frameworks where numerous rebellious require concurrent communication channels.

Avionics and Aerospace

Suitable for flight recreation frameworks and flying machine testing stages requiring dependable multi-channel communication.

Process Control Systems

Excellent for monitoring and controlling multiple sensors and actuators in manufacturing environments.

Data Acquisition Networks

Optimal for disseminated estimation frameworks collecting information from various inaccessible devices.

Core Functionality

Advanced Transmission Control

Software-configurable timing transmission with 1μs determination empowers exact outline timing control. The framework bolsters timing interims from 1μs up to (2³²-1)μs between outline starts.

Flexible Reception Modes

Choose between straightforward gathering and convention gathering modes. Convention gathering underpins setups 0-12 with both revive and FIFO gathering alternatives available.

Intelligent Data Management

Each channel features independent 8K transmit buffers and 8M receive buffers. Individual FIFO reset and receive enable controls provide granular channel management.

Robust Error Handling

Built-in timeout and outline misfortune measurements with configurable timeout ranges. The framework consequently tracks misplaced outlines and gives software-accessible counters for demonstrative purposes.

Key Features

• Multi-Bus Compatibility: Underpins PXIe, CPCI, PCIe, and PCI transport standards
• High-Speed Execution: Information rates up to 4Mbps with exact timing control
• Flexible Setup: Software-selectable communication parameters
• Surge Security: Built-in assurance for all input/output ports
• Large Buffer Capacity: Liberal buffer sizes avoid information loss
• Interrupt Bolster: Configurable hinder modes for productive information handling
• Wide Temperature Run: Industrial-grade operation from -40℃ to +70℃
• Comprehensive Computer program Bolster: Windows and Linux drivers included

Custom Design Services

We understand that every application has unique requirements. Our engineering team provides comprehensive customization services to adapt the 12-Channel Serial Communication Card for your specific needs. From modified firmware configurations to custom mechanical designs, we work closely with you to deliver tailored solutions.

Our OEM/ODM services include protocol modifications, specialized connector arrangements, and extended temperature range options. Contact our technical team to discuss your custom requirements and timeline.

Why Choose MXTD？

12+ Years Industry Experience

Since 2014, Xi'an Mingxi Taida has created profound mastery in estimation and control frameworks. Our broad encounter guarantees demonstrated arrangements for your most challenging applications.

Expert R&D Team

Our committed inquire about and advancement group ceaselessly innovates to keep up industry authority. We contribute intensely in progressed innovations to give cutting-edge solutions

Comprehensive Quality Assurance

Strict quality control forms guarantee each card meets thorough measures. Progressed mechanization and standardized strategies ensure reliable item reliability.

Responsive Technical Support

Our proficient after-sales group gives fast investigating help and normal follow-ups to guarantee your continued satisfaction.

Secure Logistics Partnership

We partner with reliable logistics providers to ensure safe, timely delivery with full tracking and insurance coverage.

Frequently Asked Questions

Q: Can this card work with LabVIEW applications?

A: Yes, we provide LabVIEW drivers and support LabVIEW RT environments for seamless integration.

Q: What's the maximum cable length for RS422 connections?

A: RS422 standard supports up to 1200 meters at lower baud rates, with shorter distances for higher speeds.

Q: Is the card compatible with existing NI systems?

A: Yes, our design meets NI product model requirements for easy integration into existing setups.

Q: Can I modify the communication protocols?

A: Absolutely. We offer customization services to adapt protocols according to your specific requirements.

Q: What operating systems are supported?

A: Standard support includes Windows 98/2000/2003/XP/7/10, with custom support for Linux/VxWorks/RTX available.
