UTI320E Handheld Infrared Thermal Imager

UNI-T UTi320E Professional Thermal Imager

UNI-T UTi320E 320×240 high resolution thermal imaging camera from official supplier, -20℃~550℃ measurement range, built-in WiFi & Type-C, IP54 rugged design for electrical, HVAC and building thermal inspection with 1-year manufacturer warranty.

Product Description from the Supplier

When you need dependable non-contact thermal inspection solutions for maintenance and diagnostic applications, our UTi320E Professional Thermal Imager delivers outstanding imaging performance and functional flexibility. These industrial-grade handheld thermal cameras feature native 320×240 infrared pixel resolution, engineered to satisfy rigorous testing demands of electrical troubleshooting, HVAC servicing, building envelope auditing and mechanical equipment condition monitoring. With full support for wireless WiFi transmission, Type-C data & charging connection, PC software and mobile APP analysis, these thermal imagers provide the adaptability you require for diverse field inspection environments.

Description

The UNI-T UTi320E is a handheld uncooled vanadium oxide thermal imager designed for professional on-site temperature detection. Adopting advanced infrared sensing technology, the device combines infrared thermal image and visible light shooting into one unit, supporting image fusion and PIP display. Users can perform multi-form temperature measurement, set high-low temperature alarms and adjust material emissivity flexibly. Saved images can be stored on Micro SD card and transmitted via WiFi or Type-C to mobile phones and computers for subsequent analysis. Built to IP54 waterproof and dustproof standard and passed 2m drop test, this thermal camera works steadily in complex industrial and construction working scenes with English & Chinese bilingual operating system for global operators.

Specifications

Applications

• Electrical maintenance: Overheat check of cables, switches, motors and distribution boxes.
• HVAC industry: Heating pipeline blockage detection and air conditioner fault inspection.
• Building inspection: Wall heat loss, insulation damage and hidden water leakage testing.
• Mechanical industry: Abnormal high-temperature diagnosis of bearings and running equipment.
• Household maintenance: Underfloor heating leakage and home appliance overheat detection.

Functionality

• Four image output modes: Thermal, Visible, Fusion and PIP adjustable display.
• Multiple measuring tools: Point, line, circle and rectangular region temperature analysis.
• Seven optional color palettes for better heat spot identification.
• Customizable high/low temperature alarm with screen and LED prompt.
• Parameter adjustment: Emissivity, date&time, screen brightness and auto shutdown time.
• Image storage in JPG format, QR code classification and picture remark editing.
• WiFi wireless transmission and Type-C charging & data export.

Key Features

• 320×240 high-definition infrared core captures tiny temperature variations.
• Adjustable emissivity adapts to wood, metal, concrete, skin and dozens of common materials.
• Free PC software & mobile APP support real-time preview and offline data analysis.
• Built-in flashlight facilitates measurement under dark working conditions.
• User-friendly menu with Chinese and English switchable system language.
• Rugged industrial casing adapts to various harsh construction and workshop environments.

Custom Design

We provide bulk order customized service for global distributors and enterprise clients:

• Custom package labeling and private logo printing on product shell.
• Batch parameter pre-set according to customers’ regular inspection scenarios.
• Bulk preferential pricing for large quantity procurement.

Why Select MXTD

• Authorized supplier of UNI-T thermal imaging products with genuine guaranteed quality.
• Strict pre-delivery inspection for every UTi320E unit to ensure stable measurement precision.
• Complete after-sales technical support and global one-year warranty service.
• Flexible customization solutions to satisfy wholesale and project purchasing demands.
• Fast global logistics and reliable after-sale consultation online.

FAQ

Q1: How long is the preheat time before accurate measurement?

A1: Preheat 30 minutes after startup for high precision testing, especially after long standby or big ambient temperature change.

Q2: Can temperature units be switched?

A2: Yes, users can switch among ℃, ℉ and K in system setting page.

Q3: Where can I download analysis APP and PC software?

A3: Free official software download link can be provided after order confirmation.

Q4: What storage card does the device support?

A4: Standard Micro SD card for local image storage in JPG format.

Q5: What does the warranty cover?

A5: 1-year warranty covers manufacturing defects; damage from misuse, falling or improper modification is excluded.
