LX2920 16-SPST Switching Type - High-power rotating dispatch center

If you need: Using a high-power power supply/load, test multiple battery modules, multiple motor drivers, and multiple power modules; Perform long-term and repeated automatic switching under high current (60A+) and high voltage (hundreds of volts). Strive for the lowest line loss and the safest electrical isolation; Then, LX2920 is the "high-power rotational dispatch center" tailor-made for you.

Description

LX2920 is a 16-channel high-power multiplexing switch module.It can safely and with low loss automatically switch a single high-current power supply or load to up to six tested devices in a sequential manner. It is an ideal choice for achieving resource reuse and building an efficient aging and lifespan testing system.

Specifications

model	LX2920	PXI2931A
Bus	LXI	PXI
Switching Type	SPST	SPST
Number of Channels	16	16
Maximum Switching Voltage(for resistive load)	300 VDC	30 VDC / 250 VAC

Maximum Switching Current(for resistive load)	60 A	5 A (DC) / 5 A (AC)
Maximum Switching Power(for resistive load)	60 A / 80 VDC or20 A / 300 VDC	150 W / 1250 VA
Maximum Relay Contact Resistance	≤ 0.2 mΩ	≤ 30 mΩ
Path DC Resistance	≤ 30 mΩ	≤ 100 mΩ
Relay Operating Life(for resistive load)	1 x 10⁶ cycles	1 x 10⁶ cycles
Relay Operate (Pick-up) Time	≤ 15 ms	≤ 10 ms
Relay Release (Drop-out) Time	≤ 12 ms	≤ 5 ms
Maximum Relay Operating Frequency	1200 cycles/hour	1800 cycles/hour
Connector Type	IXZ-2 Terminal Post	DB-37 (Plug) Connector
Operating Temperature	0°C ~ +50°C	0°C ~ +50°C
Storage Temperature	-40°C ~ +70°C	-40°C ~ +70°C
Operating Humidity	10% ~ 90%, non-condensing	10% ~ 90%, non-condensing
Storage Humidity	5% ~ 95%, non-condensing	5% ~ 95%, non-condensing
Dimensions / Form Factor	2U Full Rack	PXI Single Slot, 3U Standard Module

Applications

No matter which industry you are in, if you encounter a scenario where "a high-power power supply/laboratory load needs to test multiple high-power devices in rotation", then the LX2920 is the core tool that can help you reduce testing costs and increase equipment utilization.

1.Battery and energy storage cell testing
2. Testing of Electric Motor Controllers for New Energy Vehicles
3. Aging Test of Industrial Power Supplies and UPS
4. Testing of Power Distribution Units (PDU) for Aerospace Power Suppli

Functionality

An automatic rotary switch with one input and six outputs, specifically designed to safely and efficiently switch extremely high currents and voltages with minimal loss, allowing a single high-power source to serve multiple DUTs in sequence.

1. High-Power Multiplexing (16 MUX)

2. High Current / High Voltage Switching

3.Extremely Low Conduction Loss

4.Automated Sequential Control

5.Safe and Reliable Electrical Isolation

6.High-Current Dedicated Interfaces

Key Features

1. Automatically switch a single high-power resource (such as power supply, electronic load) to up to 6 different test devices, achieving multi-purpose utilization of a single source.
2. Support continuous current switching of 60A or above (some models can reach 100A+), and support high-voltage switching of hundreds of volts DC/AC (such as 400V, 1000V).
3. Low contact resistance: The contact resistance of relays is usually ≤ 0.5mΩ, and can even reach ≤ 0.1mΩ.
4. Programmed switching: Support automatic channel switching according to preset programs via LXI (Ethernet), GPIB or RS-232 interfaces.
5. Channel isolation: Each output channel is isolated from each other to prevent mutual influence when the tested equipment fails.
6. Connection method: Use large current terminals, bolt terminals or Anderson connectors to ensure a secure connection and eliminate loosening and overheating.

Custom Design

supports comprehensive customization, from electrical parameters and channel topology to control interfaces and thermal structures, ensuring the high-power switch module

perfectly matches your specific test scenario.

1. Electrical Parameter Customization 2. Channel Topology Customization 3. Interface and Connection Customization

4. Control Interface & Communication Protocol Customization 5. Thermal and Mechanical Structure Customization 6. Special Function Customization

Customization Process

Why Choose MXTD?

Deep Industry Encounter: With over 12 years in estimation and control frameworks, we get it the challenges you confront and convey arrangements that work.

Expert Designing Group: Our gifted R&D experts drive persistent advancement while providing specialized bolster all through your venture lifecycle.

Quality Affirmation: Thorough testing and quality control forms guarantee each item meets tall benchmarks for unwavering quality and performance.

Comprehensive Bolster: From beginning discussion through continuous upkeep, our group gives the skill you require for effective extend completion.

Flexible Arrangements: Whether you require standard items or custom plans, we provide arrangements that coordinate your particular prerequisites and budget.

Certifications and Certificates

Logistics and Transportation

FAQ

Q:What is the maximum current this module can handle?

A: The standard version supports 60A continuous current, and can be customized for 100A, 200A, or even higher based on requirements.

Q:Does it generate excessive heat during switching? Will it burn out?

A: No, it won't. With contact resistance ≤0.5mΩ (as low as 0.1mΩ), power dissipation per channel at 60A is only about 1.8W. Combined with dedicated thermal design, it ensures stable long-term operation.

Q:What does "1.6-channel" mean? Is it 1 input and 6 outputs?

A: Yes, exactly. 1 common input channel (connect to power supply/load) and 6 branch output channels (connect to DUTs), allowing one power supply to sequentially serve six devices.

Q:Does it support automated control? How do I program it?

A: Yes, it does. Standard LXI (Ethernet) interface, with optional GPIB and RS-232. Provides IVI drivers, supporting LabVIEW, Python, C++, and other programming environments.

Q:Can I use it in my existing aging test system?

A: Yes, you can. Standard communication interfaces and protocols allow quick integration into existing systems. Custom protocols are also available upon request.

Contact Us

Designed specifically for the scenario of "one high-power source measuring multiple test objects", it adopts the most extreme high-power engineering design and resource reuse to achieve efficient, safe and low-loss automated polling tests.

Contact our sales team at manager03@mxtdinfo.com to discuss your requirements, request detailed specifications, or arrange product demonstrations. We look forward to helping you achieve your measurement and control objectives with our reliable switching technology.
