PXI5020IL 8-Channel 3U VPX Single Board Computers – 8-Port RS-232/422/485 Interface Solution

The PXI5020IL is an 8-Channel 3U VPX Single Board Computers communication module that supports RS-232, RS-422, and RS-485 protocols. Each channel operates independently and provides electrical isolation, ensuring reliable communication and effective protection against noise and ground loops.

The module allows flexible configuration of serial standards, baud rates, and communication parameters through software, making it suitable for a wide range of industrial control, data acquisition, and automated test applications.

Product Description from the Supplier

Xi'an Mingxi Taida Information Technology Co., Ltd. brings over 12 years of industry expertise to deliver cutting-edge measurement and control solutions. Our designing group specializes in PXIe chassis sheets, coordinates testing items, and accuracy instrument fabricating. With progressed computerization forms and strict quality control, we guarantee each item meets the most noteworthy guidelines for proficient applications.

Description

The PXI5020IL 8-Channel 3U VPX Single Board Computer integrates eight isolated serial ports into a single PXI slot, enabling high-density and flexible serial communication within PXI-based test systems. Each channel can be independently configured as RS-232, RS-422, or RS-485, allowing mixed-protocol operation in a single module.

With built-in isolation and industrial-grade design, the PXI5020IL ensures stable data transmission in electrically noisy environments, making it ideal for long-term, high-reliability system deployments.

Specifications

Parameter	Specification
Model	PXI5020IL
Number of Ports	8
Supported Protocols	RS-232 / RS-422 / RS-485 (software configurable)
Isolation Voltage (per channel)	≤ 1500 VDC
FIFO Depth	64 bytes
Baud Rates (bps)	600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 921600
Operating Temperature	–10°C to +55°C
Storage Temperature	–40°C to +70°C
Operating Humidity	10%–90%, non-condensing
Storage Humidity	5%–95%, non-condensing

Applications

Industrial automation and control systems
PXI-based automated test equipment (ATE)
Serial device communication and monitoring
Data acquisition and logging systems
Electrical isolation in noisy environments

Functionality

Independent configuration of each serial port
Supports mixed RS-232/422/485 operation on one module
Electrical isolation for improved signal integrity
High baud rate support up to 921.6 kbps
Seamless integration into PXI systems

Key Features

8 isolated serial communication channels
Software-selectable RS-232/422/485 per port
High isolation voltage for enhanced system safety
Wide baud rate range for legacy and modern devices
Compact PXI 3U single-slot design
Reliable operation in industrial environments

Custom Design

We get it that standard arrangements do not continuously meet one of a kind prerequisites. Our experienced building group gives comprehensive OEM/ODM customization administrations. Whether you require adjusted recurrence ranges, specialized activating alternatives, or custom frame components, we work closely with you to create the idealize arrangement. Our adaptable plan approach guarantees your particular application needs are completely tended to whereas keeping up our quality standards.

Customization Process

Why Select MXTD

Proven Encounter: Over 12 a long time of specialized skill in estimation and control frameworks development.

Expert Designing: Our gifted R&D group ceaselessly innovates to convey cutting-edge arrangements that keep you ahead of industry demands.

Quality Confirmation: Strict fabricating forms and comprehensive testing conventions guarantee dependable, steady performance.

Comprehensive Back: From starting meeting through progressing support, our committed group gives responsive specialized assistance.

Secure Conveyance: Collaborating with trusted coordinations suppliers guarantees secure, followed, and safety net provider shipment of your equipment.

Customer Center: We prioritize your victory with standard follow-ups, fast issue determination, and personalized benefit approaches.

Certifications and Certificates

Logistics and Transportation

FAQ

Q: What waveform sorts can this generator produce?

A: The framework produces sine waves, square waves, triangle waves, slope waves, anti-ramp waves, and user-defined self-assertive waveforms.

Q: Is the unit consistent with existing NI systems?

A: Yes, our plan meets NI item demonstrate necessities for consistent integration.

Q: Can different serial standards be used on the same module?
A: Yes, each port can be independently configured as RS-232, RS-422, or RS-485.

Q: Does the module provide electrical isolation?
A: Yes, each channel features electrical isolation to improve reliability and safety.

Q: What is the maximum supported baud rate?
A: The PXI5020IL supports baud rates up to 921.6 kbps.

Contact Us

Looking for a reliable, high-density PXI serial communication solution?

Our technical team is ready to help you integrate the PXI5020IL 8-Channel 3U VPX Single Board Computers into your test or control system. Whether you need a standard configuration or a customized solution, MXTD is here to support your project.

Reach out to our team today: manager04@mxtdinfo.com
