NI-9213 C-Series Thermocouple Input Module

The NI-9213 is a high-precision 16-channel thermocouple input module, it designed specifically for high-channel-count temperature measurement systems. This module can be installed in CompactDAQ and CompactRIO chassis, providing a compact thermocouple measurement solution for mixed-signal test systems.

Product Description from the Supplier

Xi'an Mingxi Taida Information Technology Co., Ltd. brings over 12 years of industry expertise to deliver cutting-edge measurement and control solutions.With progressed computerization forms and strict quality control, we guarantee each item meets the most noteworthy guidelines for proficient applications.

Description

Key Advantages of the NI-9213 C-Series Thermocouple Input Module

• Highest single-module channel density (16 channels)
• Lowest cost per channel
• Flexible spring terminal connections
• Built-in automatic zeroing and cold junction compensation

The NI-9213 is positioned as a high-density solution within NI's C-series thermocouple module product line

Measurement Sensitivity

The NI-9213 is available in two connector versions:

• Standard spring terminals
• Push-in spring terminal

Connection Features and Advantages:

• No soldering required, quick wiring
• Supports single-strand and multi-strand wires (with cold-press head)
• Push-in version supports tool-free wiring

Environmental Adaptability

The NI-9213 C-Series Thermocouple Input Module is designed to address the three major pain points of high-channel-count temperature measurement systems:

• If you need to solve too many slots occupied: NI-9213 designed the 16-channel high-density design, 128 channels can be provided with 8 modules
• If you need to solve Insufficient measurement accuracy: This module designed 24-bit ADC + Automatic Zeroing + CJC Triple Protection
• If you need to solve the system complexity is too high: This module designed Integrated anti-aliasing filter simplifies system

Application:

✅Automobile- Vehicle thermal management test, engine temperature rise test, climate chamber test

✅Aerospace- Aircraft thermodynamic testing and engine compartment temperature monitoring

✅Energy- Battery pack temperature monitoring and photovoltaic panel testing

✅Industry- Furnace temperature monitoring and heat treatment process control

✅Research- Material thermal performance testing and environmental chamber temperature recording

✅Semiconductor- Wafer processing temperature

NI-9213 Vs NI-9211: 4x channel density, suitable for large-scale temperature monitoring. Vs NI-9214: Higher sampling rate, lower price. Vs competitors: NI brand guarantee + LabVIEW ecosystem support.

The auto-zero channel is a dedicated internal channel built into the NI-9213 C-Series Thermocouple Input Module for measuring and compensating for system offset errors. Measurement accuracy can be significantly improved by subtracting the auto-zero value from each thermocouple reading.

Accuracy Improvement:

• Offset Error in High-Resolution Mode: 4 µV (Typical) / 6 µV (Maximum)
• Offset error is further reduced after enabling auto-zeroing

Dual timing mode

• High-resolution mode: Conversion time: 55 ms/channel. Sampling rate: 1 S/s (all channels). Features: Highest accuracy, 50/60Hz noise suppression (60 dB).
• High-speed mode: Conversion time: 740 µs/channel. Sampling rate: 75 S/s (all channels). Features: High sampling rate, wide signal bandwidth (78 Hz)

The NI-9213 has a built-in hardware anti-aliasing filter that follows the Nyquist sampling theorem to ensure no frequency aliasing at the sampling frequency.

Input Bandwidth and Noise

NI-DAQmx supports the following programming environments

Custom Design

We get it that standard arrangements do not continuously meet one of a kind prerequisites. Our experienced building group gives comprehensive OEM/ODM customization administrations. Whether you require adjusted recurrence ranges, specialized activating alternatives, or custom frame components, we work closely with you to create the idealize arrangement. Our adaptable plan approach guarantees your particular application needs are completely tended to whereas keeping up our quality standards.

Why Choose MXTD?

Proven Experience

With over 12 years in the industry, we understand your challenges and deliver solutions that work.

Quality Assurance

Strict quality control processes ensure every board meets our high standards for reliability and performance.

Comprehensive Support

Our technical team provides ongoing assistance from initial consultation through long-term maintenance.

Fast Response

We respond quickly to your needs, whether for standard products or custom solutions.

Reliable Delivery

Partnering with trusted logistics providers ensures your orders arrive safely and on time.

Notes:

​​​​​​​To achieve optimal measurement accuracy, please follow these guidelines:

✅Use small-gauge thermocouple wires: Reduce heat transfer to/from the terminal junction

✅Avoid proximity to heat/cold sources: Keep thermocouple wires away from hot or cold objects

✅Mize adjacent heat sources and airflow: Minimize heat sources and airflow near the terminals

✅Maintain stable ambient temperature: Avoid drastic temperature fluctuations

✅Module orientation: Ensure the NI-9213 terminals are facing forward or upward

✅Maintain stable orientation: Do not frequently change the module orientation

✅Wait for thermal equilibrium: Wait for the thermal gradient to stabilize after system power changes

✅Bundle wiring: Bundle thermocouple wires near the spring terminal connector

✅Use extension wires of the same material: If extension wires are required, use wires of the same material as the thermocouples

✅Use the NI-9940 back cover kit: Protect connections in high-vibration applications
