YFS8-24ZJ-01 or TK-01 Separation (Breakaway) Electrical Connector

YFS8-24ZJ-01/TK-01 Separation (Breakaway) Electrical Connector | 30m Underwater Sealed, 24-Contact Hybrid Interface

The YFS8‑24ZJ‑01/TK‑01 Separation Connector series takes underwater reliability to the next level, offering certified sealing at 30 m depth for both mated and unmated conditions. With 24 hybrid contacts—four 16# (10 A) and twenty 22# (5 A)—it delivers ample capacity for power and signal circuits in a single breakaway interface. Solder termination ensures field‑proven dependability, while the calibrated 50–100 N separation force (with 15° angular tolerance) guarantees positive release even in non‑ideal pull directions. Qualified to rigorous vibration, shock, and acceleration standards, the YFS8‑24‑01 is the preferred choice for submarine-launched systems, underwater vehicles, and aerospace applications where water ingress is not an option.

Product Descriptions from the Supplier

The YFS8‑24ZJ‑01/TK‑01 Separation (Breakaway) Electrical Connector is a high‑performance interconnect solution engineered for the most demanding underwater and aerospace separation events. Fully compliant with enterprise standard Q/21EJ1273, this connector features a unique dual‑seal design that maintains IP68‑equivalent protection at 30 m water depth when mated, and ensures the receptacle alone can withstand 30 m water pressure for over 50 hours without internal shorting (insulation resistance ≥2 MΩ during and after exposure).

The contact complement consists of four 16# contacts rated at 10 A (≤8 mΩ) for moderate power or control circuits, and twenty 22# contacts rated at 5 A (≤15 mΩ) for signal and low‑power applications—a total of 24 circuits in a compact shell. All contacts are terminated via solder cups, offering reliable, field‑serviceable connections suitable for prototyping, maintenance, and production.

Mechanical separation is calibrated to 50–100 N, with the unique ability to tolerate a 15° off‑axis pull angle, ensuring reliable release even when cable routing is not perfectly aligned. The connector withstands severe dynamic environments: random vibration (0.04 G²/Hz from 10–1000 Hz, then –6 dB/oct to 2000 Hz, 7.72 Grms), sinusoidal vibration of 150 m/s², shock of 50 g, and constant acceleration of 490 m/s². With a mechanical life of 500 mating cycles, it is suitable for repeated ground testing and operational reuse.

Available in two configurations:

• YFS8‑24TK‑01: Plug (cable‑attached half) with socket contacts
• YFS8‑24ZJ‑01: Receptacle (panel‑mount half) with pin contacts

Typical applications include underwater vehicle tether release, submarine‑launched systems, naval buoy deployment, and aerospace stage separation where water exposure is a critical concern.

Specifications

Applications

• Underwater Vehicles: Tether release, emergency disconnect.
• Naval Systems: Submarine‑launched equipment, buoy deployment, torpedo interfaces.
• Aerospace: Stage separation, payload release, umbilical disconnects exposed to weather.
• Offshore Energy: ROV tooling, subsea sensor networks.
• Defense: Marine mine countermeasures, underwater surveillance.
• Industrial: High‑pressure washdown environments, submerged instrumentation.

Functionality

• 30m Underwater Sealing: Mated connector withstands 30 m depth; unmated receptacle endures 30 m pressure for ≥50 h with insulation ≥2 MΩ.
• Controlled Separation Force: 50–100 N breakaway with 15° off‑axis tolerance ensures reliable release despite cable misalignment.
• Hybrid Contact Set: Four 16# (10 A) plus twenty 22# (5 A) for mixed power and signal circuits.
• Solder Termination: Dependable, field‑serviceable connections without special tooling.
• Environmental Robustness: Withstands extreme temperature, vibration, shock, and acceleration.
• High Contact Density: 24 circuits in a compact footprint reduces system complexity.

Key Features​​​​​​​

• Certified 30m Underwater Protection: Exceeds typical splashproof ratings—true underwater capability.
• Off‑Axis Pull Tolerance: 15° angular allowance prevents nuisance release or hang‑ups.
• Hybrid Power/Signal Contacts: 10 A and 5 A circuits in one connector.
• Solder Termination: Reliable, easy to repair in field or lab.
• Aerospace‑Grade Qualification: Tested to MIL‑style vibration, shock, and acceleration.
• 500‑Cycle Life: Adequate for test and operational reuse.
• Wide Temperature Range: -55 °C to +125 °C suits harsh environments.
• High Insulation Resistance: >1000 MΩ at room temp, >20 MΩ after humidity.

Custom Design

The YFS8‑24‑01 platform can be tailored to meet specific mission needs:

• Custom Contact Mix: Adjust quantities of 16# and 22# contacts, or add other sizes.
• Separation Force Adjustment: Modify breakaway force for unique release requirements.
• Enhanced Sealing: Higher pressure ratings or different sealing materials available.
• Special Materials: Select shell finishes for enhanced corrosion resistance.
• Cable Assembly Integration: Complete harness solutions with soldered contacts and overmolding.
• Non‑Standard Testing: Additional screening for high‑reliability programs.

Why Choose MXTD

At MXTD, we specialize in separation connectors that perform where others fail—underwater, under vibration, and under pressure. The YFS8‑24‑01 series exemplifies our commitment to engineering excellence, combining 30 m sealing, off‑axis pull tolerance, and hybrid power/signal contacts in a single, rugged package. Manufactured under strict enterprise standard Q/21EJ1273, each unit undergoes comprehensive testing including pressure validation, separation force calibration, and dynamic stress screening. Our team brings decades of experience in naval and aerospace separation systems, working closely with customers to ensure that every interface meets the unique demands of the mission. When you choose MXTD, you're partnering with a dedicated team focused on the success of your program, from prototype to production.

FAQ

Q: What does "30m underwater sealing" mean exactly?
A: When mated, the connector remains fully sealed at 30 m water depth. Additionally, the unmated receptacle can withstand 30 m water pressure for at least 50 hours without internal shorting, maintaining insulation resistance ≥2 MΩ.

Q: What is the separation force range?
A: The mechanical separation force is calibrated between 50 N and 100 N, and the mechanism tolerates a pull direction up to 15° off the connector axis.

Q: How many contacts are there, and what are their ratings?
A: There are 24 contacts total: four 16# contacts rated at 10 A (≤8 mΩ) and twenty 22# contacts rated at 5 A (≤15 mΩ).

Q: What termination method does this series use?
A: Termination is via solder cups, providing reliable, field‑serviceable connections.

Q: What is the operating temperature range?
A: The connector operates from -55°C to +125°C.

Q: What vibration and shock levels can it withstand?
A: It withstands random vibration (0.04 G²/Hz, 7.72 Grms), sinusoidal vibration of 150 m/s², shock of 50 g, and constant acceleration of 490 m/s².

Q: What is the difference between YFS8‑24TK‑01 and YFS8‑24ZJ‑01?
A: YFS8‑24TK‑01 is the plug (cable‑attached half) with socket contacts; YFS8‑24ZJ‑01 is the receptacle (panel‑mount half) with pin contacts.

Q: What is the insulation resistance after environmental testing?
A: After high temperature and humidity testing, insulation resistance remains >20 MΩ.

Q: Do you provide mating connectors?
A: Yes, both plug and receptacle versions are available. Please specify your configuration when ordering.
